Watts FD-340 User Manual

Fd-340, Area drain with 12" adjustable top

background image

ES-WD-FD-340 USA 1348

FD-340

Tag:

SPECIFICATION:

Watts Drainage FD-340 epoxy coated cast iron area drain with anchor flange, body collar with weepholes,

12-1/2"(318) diameter adjustable top with heel proof ductile iron grate, and no hub (standard) outlet.

Area Drain with

12" Adjustable Top

FD-340

* The load classifications are in accordance with the

American National Standards ASME A112.21.1M

ASME Ratings are as follows:

XHD - Safe Live Load 7500-10000 lbs.(3375-4500kg)

The above categories are given as a guide only.

Please consult factory.

Load Rating & Free Area

Load

Free Area

Rating

Sq. In.

*XHD

37

Components

B2-CB

-5

Sediment Bucket

-6

Vandal Proof

-7
-8

Backwater Valve (2, 3, 4" Only)

-13

Galvanized Body

-F4-50 4" Round Cast Iron Funnel
-F4-1 4" Round Nickel Bronze Funnel
-F6-1 6" Round Nickel Bronze Funnel
-G-50 4x9" Oval Cast Iron Funnel
-G-1

4x9" Oval Nickel Bronze Funnel

Options (Select One or More)

Suffix Description

No Hub (MJ)
Push On

P

Threaded Outlet
Inside Caulk

X

Trap Primer Tapping

Outlet Type (Select One)

Suffix Description

2"(51) Pipe Size

2

3"(76) Pipe Size

3

4"(102) Pipe Size

4

6"(152) Pipe Size

6

Pipe Sizing (Select One)

Suffix Description

PVC Body (2,3,4,6" Only)

-60

ABS Body (2,3,4" Only)

-61

Optional Body Material

Suffix

Description

NH

-34

Closure Plug

5"(127) Pipe Size (NH Only)

5

8"(203) Pipe Size (NH Only)

8

-21

Secondary Strainer

-1

Nickel Bronze Top

5-7/8” (149) MAX

4-3/4” (121) MIN

2-1/2” (64)

6-1/4” (159)

PIPE SIZE

12-1/2” (318)

12” (305)

FC-1

B2

FD-340

-US

Buy American Compliant

-DG

Dome Grate

-SO

Side Outlet (2,3,4” Only)

T
