For Residential and Commercial Polyethylene Pipe Applications

ES-TR18P1-TEES

Job Name –––––––––––––––––––––––––––––––––––––––––––– Contractor

––––––––––––––––––––––––––––––––––––––––––––

Job Location –––––––––––––––––––––––––––––––––––––––––– Approval

––––––––––––––––––––––––––––––––––––––––––––––

Engineer –––––––––––––––––––––––––––––––––––––––––––––

Contractor’s P.O. No. –––––––––––––––––––––––––––––––––––

Approval ––––––––––––––––––––––––––––––––––––––––––––– Representative

–––––––––––––––––––––––––––––––––––––––––

Series TR18P1

TRITON

Tee Fittings

Sizes:

3

4

" – 2" (20 – 50mm)

TRITON Series TR18P1 tee fittings are used to connect three

pieces of polyethylene pipe. The fittings are manufactured of

PE 4710 and are compatible with most polyethylene piping ma-

terials (Consult ES-TRPE-Comp for compatibility information).

The fittings are designed to be used with the TRITON TRCU1

Control Unit and TRFWP1 Fusers to complete the connection.

Specifications

The system shall be plumbed using Watts TRITON Pipe Fusion

fittings. Each fitting will incorporate the patent-pending TRI-

TON Fuse-Tel™ fusion indicator that will provide a visual and

tactile indication that the weld has been successfully complet-

ed. The TRITON Pipe Fusion system will operate on 110/115

VAC power and utilize a 13.56MHz ISM band frequency in

conjunction with a dual susceptor embedded in the fitting to

complete the fuse.

TR18P1

MODEL

INLET

OUTLET

BRANCH

DIMENSIONS

WEIgHT

SIZE (DN)

SIZE (DN)

SIZE (DN)

A

B

C

D

E

in.

mm

type

in.

mm

type

in.

mm

type

in.

mm

in.

mm

in.

mm

in.

mm

in.

mm

lbs.

kgs.

TR18P1-121212-IPS

3

/

4

20

IPS

3

/

4

20

IPS

3

/

4

20

IPS

5

5

/

8

144

2

1

/

4

57

1

11

/

16

42

2

13

/

16

71

3

11

/

16

93

.22

.1

TR18P1-161616-IPS

1

25

IPS

1

25

IPS

1

25

IPS

6

152

2

1

/

4

57

2

51

3

76

4

101

.32

.144

TR18P1-202020-IPS 1

1

/

4

32

IPS

1

1

/

4

32

IPS

1

1

/

4

32

IPS

6

5

/

16

160

2

1

/

4

57

2

3

/

8

60

3

1

/

8

80

4

5

/

16

110

.42

.188

TR18P1-242424-IPS 1

1

/

2

40

IPS

1

1

/

2

40

IPS

1

1

/

2

40

IPS

7

5

/

8

194 2

13

/

16

71

2

11

/

16

69

3

13

/

16

97

5

3

/

16

132

.65

.293

TR18P1-323232-IPS

2

50

IPS

2

50

IPS

2

50

IPS

8

3

/

16

207 2

13

/

16

71

3

5

/

16

85

4

1

/

16

104

5

3

/

4

146

.99

.451

Dimensions — Weights

Installation Notes

• Fitting and pipe must be free of grease, oils, water, and debris.

Wipe each fitting and pipe end before insertion of pipe into fitting.

• Pipe must be inserted to the correct depth "B" inside the fitting.

Use the depth gauge on the side of the fitting to properly mark

the required insertion depth on the pipe.

Standards

Manufactured in accordance with American Society

for Testing and Materials

ES-TR18P1-TEES 1308

© 2013 Watts

USA: Tel: (978) 688-1811 • Fax: (978) 794-1848 • www.watts.com
Canada: Tel: (905) 332-4090 • Fax: (905) 332-7068 • www.watts.ca

Watts product specifications in U.S. customary units and metric are approximate and are provided for reference only. For precise measurements, please contact Watts Technical Service. Watts
reserves the right to change or modify product design, construction, specifications, or materials without prior notice and without incurring any obligation to make such changes and modifications
on Watts products previously or subsequently sold.

A Watts Water Technologies Company

E

D

A

B

INLET

OUTLET

C

C

TM

BRANCH
