Page 2
Model
order No.
Size
Material
Max. teMp./
preSSure
MaSter
CartoN No.
pieCeS
Weight
(lbS.)
lFtp-N (Neoprene)
0123012
1
⁄
4
" NPT
Lead Free* Brass 200°F-500psi
180
17
lFtp-e (EPDM)
0123005
1
⁄
4
" NPT
Lead Free* Brass 275°F-500psi
180
17
lFtp-V (Viton
®
)
0123008
1
⁄
4
" NPT
Lead Free* Brass 400°F-500psi
180
17
lFtp-N (Neoprene)
0123013
1
⁄
2
" NPT
Lead Free* Brass 200°F-500psi
72
14
lFtp-e (EPDM)
0123006
1
⁄
2
" NPT
Lead Free* Brass 275°F-500psi
72
14
extensions
lFtp-x (3")
0123007
1
⁄
4
"m x
1
⁄
4
"f Lead Free* Brass
90
23
lFtp-x (3")
0123009
1
⁄
2
"m x
1
⁄
2
"f Lead Free* Brass
36
23
gauges
lFdpg1-30
0121638
1
⁄
4
" NPT
Lead Free* Brass
Copper bourdon
tube socket
185°F-30psi
40
.06
lFdpg1-160
0121641
1
⁄
4
" NPT
185°F-160psi
40
.06
lFdpg1-300
0121643
1
⁄
4
" NPT
185°F-300psi
40
.06
gauge adaptors
lFtp-ga1
0123044
1
⁄
4
" NPT
Lead Free* Brass
Body 300 Series
SS Probe
90
23
Plug Inserts Compatibility
Note: Decal on cap color coded for plug material.
Neoprene (Blue) - Natural gas and petroleum products
Temperature range: -40°F to 200°F (-40°C to 93°C)
EPDM (White) - Hot and cold water service
Temperature range: -40°F to 275°F (-40°C to 135°C)
Viton
®
(Green) - Hot oil service, chemical resistance.
Temperature range: -10°F to 400°F (-23°C to 204°C)
Note 1: Viton
®
Test Plugs are not recommended for use
with probes larger than .080 diameter or continuous leakage
may occur.
Note 2: Maximum temperature for TPG gauges is 185°F.
For Pressure
Model
TPG
Seal Cap
Model
TP-GA1
Model LFTP
2
1
⁄
2
"
7
⁄
8
"
1
⁄
4
" Npt
Male
Case and Ring - Black coated steel
Bourdon tube copper
Socket - Lead Free* Brass
Model
LFDPG1
1
⁄
4
" Npt
test plug
1
⁄
2
" Npt
test plug
1
⁄
4
" Npt
Male
1
⁄
2
" Npt
Male
Model LFTP
1
1
⁄
2
"
thermometer
1"
4
3
⁄
4
"
Model
LFTP-T
Supplied with
probe protector
and pocket clip
.140"
2
3
⁄
4
"
1
⁄
4
" Npt Female
Model
LFTP-GA1
5
⁄
8
"
hex
9
⁄
16
"
hex
1
1
⁄
2
"
ES-LFTP 1329
