Dimensions – Weights Dimensions – Weights
Size DimenSionS
Weight
H L L
1
in. in. mm in. mm in. mm lbs. kgs.
1 ⁄
2
1 3 ⁄
8
38 2 9 ⁄
16
68 3 75 0.3 0.14
3 ⁄
4
1 1 ⁄
2
40 2 3 ⁄
4
70 3 81 0.5 0.21
1 1 3 ⁄
4
50 3 7 ⁄
16
88 3 5 ⁄
8
106 0.6 0.29
L1
H
PEX
Size
L
Materials
item QtY DeSCRiPtion mAteRiAL
1 1 Handle Zinc-plated Steel w/Vinyl Handle Insulator
2 1 Stem Packing Virgin PTFE
3 1 Stem Brass
4 1 Handle Nut Brass
5 1 Body Lead Free* brass
6 2 Stem O-ring FKM
7 1 Ball Lead Free* brass
8 2 Seat Virgin PTFE
9 1 Adapter Lead Free* brass
10 1 Drain Cap Brass (LFWPBVD only)
11 1 Drain Cap Gasket EPDM (LFWPBVD only)
