Dimensions – Weights
Model Size (dN) diMeNSioNS WeiGHT
A B C D E
in. mm in. mm in. mm in. mm in. mm in. mm lbs. kg
PIPFM1-T 3 ⁄
4
20 3 ⁄
4
19 3 1 ⁄
8
80 4 101 3 1 ⁄
8
79 4 1 ⁄
8
105 2.15 0.98
1 25 1 25 3 1 ⁄
2
88 4 1 ⁄
4
108 3 1 ⁄
8
79 4 1 ⁄
8
105 2.51 1.14
1 1 ⁄
4
32 1 1 ⁄
4
31 3 13 ⁄
16
97 4 1 ⁄
4
108 3 1 ⁄
8
79 4 1 ⁄
8
105 2.97 1.35
PIPFM1-S 3 ⁄
4
20 3 ⁄
4
19 3 5 ⁄
16
84 4 101 3 1 ⁄
8
79 4 1 ⁄
8
105 2.09 0.95
1 25 1 25 3 11 ⁄
16
94 4 1 ⁄
4
108 3 1 ⁄
8
79 4 1 ⁄
8
105 2.44 1.11
1 1 ⁄
4
32 1 1 ⁄
4
31 4 1 ⁄
16
104 4 1 ⁄
4
108 3 1 ⁄
8
79 4 1 ⁄
8
105 2.88 1.31
Materials
A
A
l
K
B
B1
d
d
C
C
G
G
i
i
i
i
e
J
J
K
H
e
M
e1
F
F
Pressure – Temperature
Maximum Working Pressure: 600psi (41 bar) WOG
Maximum Temperature: 406°F (208°C) @ 100psi (6.9 bar)
A. Handle Nut Zinc Plated Steel
B. Handle Zinc Plated Steel with Vinyl Insulator
B1. Handle Die Cast Aluminum
C. Packing Nut Brass
D. Packing PTFE
E. O-Ring FKM Elastomer
E1. Thrust Washer PTFE
F. Stem
Brass
G. Ball Brass
H. Flange Brass
I. Seat PTFE
J. Adapter Brass
K. Body Brass
L. O-ring EPDM
M. Cap & Tether Brass & Polypropylene
ES-PIPFM1 1130 © 2011 Watts
USA: No. Andover, MA • Tel: (978) 688-1811 • Fax: (978) 794-1848 • www.watts.com
Canada: Burlington, ON • Tel: (905) 332-4090 • Fax: (905) 332-7068 • www.wattscanada.ca
A Watts Water Technologies Company
