Available Models

Suffix:
OSY –

UL/FM outside stem and yoke, resilient
seated gate valves

BFG –

UL/FM grooved gear operated butterfly valves

with tamper switch

*OSY FxG – Flanged inlet gate connection and grooved outlet

gate connection

*OSY GxF – Grooved inlet gate connection and flanged outlet

gate connection

*OSY GxG – Grooved inlet gate connection and grooved outlet

gate connection

Available with grooved NRS gate valves - consult factory†
Post indicator plate and operating nut available - consult factory†
†Consult factory for dimensions

Dimensions — Weight

Materials

Housing & Sleeve: 304 (Schedule 40) Stainless Steel
Elastomers: EPDM, Silicone and Buna ‘N’
Torsion Spring Checks: Noryl

®

, Stainless Steel

Check Discs: Reversible Silicone or EPDM
Test Cocks: Lead Free Silicon Copper Alloy Body Nickel Plated

(Only Center TC)

Pins & Fasteners: 300 Series Stainless Steel
Springs: Stainless Steel

Pressure — Temperature

Temperature Range: 33°F – 110°F (0.5°C – 43°C)
Maximum Working Pressure: 175psi (12.1 bar)

Approvals
