Dimensions – Weights
ModeL
InLeT
ouTLeT
Pkg. WeIghT
in.
mm
type
in.
mm
type
lbs.
kgs.
CrimpRing
™
Lead Free
*
Sweat Adapters — Male x Crimp
LFWP10B-0806PB
1
⁄
2
15
Male Sweat
3
⁄
8
10
Crimp Fitting
1
0.5
LFWP10B-0808PB
1
⁄
2
15
Male Sweat
1
⁄
2
15
Crimp Fitting
1
0.5
LFWP10B-1212PB
3
⁄
4
20
Male Sweat
3
⁄
4
20
Crimp Fitting
1
0.5
LFWP10B-1616PB
1
25
Male Sweat
1
25
Crimp Fitting
2
0.9
LFWP10B-1620PB
1
25
Male Sweat
1
1
⁄
4
32
Crimp Fitting
3
1.4
LFWP10B-2020PB
1
1
⁄
4
32
Male Sweat
1
1
⁄
4
32
Crimp Fitting
4
1.8
CrimpRing
™
Lead Free
*
Sweat Adapters — Female x Crimp
LFWP11B-0808PB
1
⁄
2
15
Female Sweat
1
⁄
2
15
Crimp Fitting
1
0.5
LFWP11B-1212PB
3
⁄
4
20
Female Sweat
3
⁄
4
20
Crimp Fitting
2
0.9
LFWP11B-1616PB
1
25
Female Sweat
1
25
Crimp Fitting
3
1.4
LFWP11B-1620PB
1
25
Female Sweat
1
1
⁄
4
32
Crimp Fitting
3
1.4
LFWP11B-2020PB
1
1
⁄
4
32
Female Sweat
1
1
⁄
4
32
Crimp Fitting
4
1.8
CrimpRing
™
Lead Free
*
Threaded Adapters — Crimp x Male
LFWP12B-0608PB
3
⁄
8
10
Crimp Fitting
1
⁄
2
15 MPT
1 0.5
LFWP12B-0808PB
1
⁄
2
15
Crimp Fitting
1
⁄
2
15 MPT
1 0.5
LFWP12B-0812PB
1
⁄
2
15
Crimp Fitting
3
⁄
4
20 MPT
2 0.9
LFWP12B-1208PB
3
⁄
4
20
Crimp Fitting
1
⁄
2
15 MPT
1 0.5
LFWP12B-1212PB
3
⁄
4
20
Crimp Fitting
3
⁄
4
20 MPT
2 0.9
LFWP12B-1216PB
3
⁄
4
20
Crimp Fitting
1
25
MPT
3
1.4
LFWP12B-1612PB
1
25
Crimp Fitting
3
⁄
4
20 MPT
3 1.4
LFWP12B-1616PB
1
25
Crimp Fitting
1
25
MPT
3
1.4
LFWP12B-2016PB
1
1
⁄
4
32
Crimp Fitting
1
25
MPT
3
1.4
LFWP12B-2020PB
1
1
⁄
4
32
Crimp Fitting
1
1
⁄
4
32 MPT
2
.9
LFWP12B-20M20CPB 1
1
⁄
4
32
MPT
1
1
⁄
4
32
Crimp Fitting
4
1.8
CrimpRing
™
Lead Free
*
Threaded Adapters — Crimp x Female
LFWP13B-0808PB
1
⁄
2
15
Crimp Fitting
1
⁄
2
15 FPT
1 0.5
LFWP13B-1212PB
3
⁄
4
20
Crimp Fitting
3
⁄
4
20 FPT
2 0.9
LFWP13B-1616PB
3
⁄
4
26
Crimp Fitting
1
25
FPT
3
1.4
LFWP13B-20F20CPB 1
1
⁄
4
32
FPT
1
1
⁄
4
32
Crimp Fitting
4
1.8
ES-WP-LFBrassAdapters 1125
© 2011 Watts
USA: No. Andover, MA • Tel: (978) 688-1811 • Fax: (978) 794-1848 • www.watts.com
Canada: Burlington, ON • Tel: (905) 332-4090 • Fax: (905) 332-7068 • www.wattscanada.ca
A Watts Water Technologies Company
This product is UL 1821 listed for PEX multipurpose systems used to support
NFPA 13D when used with Watts (Residential Fire) RF PEX
TM
Tubing, RF PEX
TM
Fittings, RF PEX
TM
Sprinkler Fittings and Copper CrimpRings
TM
. You must refer
to Watts Residential Fire at watts.com/resfire for further product specification
and safety information. DO NOT USE OTHER PRODUCTS WITHOUT SUCH
DESIGNATION IN FIRE PROTECTION APPLICATIONS.
