Flow capacity – Watts LFUSG-B User Manual
Page 2
Basic Construction
Typical Installations
Dimensions – Weights
kPa psi
620 90
551 80
482 70
413 60
345 50
276 40
207 30
138 20
69 10
0 0
Flow Capacity
0
1.00
2.00 3.00 4.00
gpm
0
3.8
7.8
11.4 15.2
lpm
LFUSG-B-M2
Two Handle Faucet
Sensor Faucet
Check Module
Ferrule
Plunger
Body
Thermostat
Temperature
Adjustment
Screw
Screen
Compression
Nut
Spring
Locking Nut
ES-LFUSG-B-M2 1149
© 2011 Watts
USA: No. Andover, MA • Tel. (978) 688-1811 • Fax: (978) 794-1848 • www.watts.com
Canada: Burlington, ON • Tel. (905) 332-4090 • Fax: (905) 332-7068 • www.wattscanada.ca
A Watts Water Technologies Company
A
B
C
D
MODEL
SIZE
DIMENSIONS
WEIGHT
A
B
C
D
in.
mm
in.
mm
in.
mm
in.
mm
lbs.
kgs.
LFUSG-B-M2
3
⁄
8
" Comp.
3
3
⁄
16
81
3
3
⁄
8
85
1
13
⁄
16
47
1
1
⁄
2
38
.82
.37
LFUSG-B-SC-M2
3
⁄
8
" Comp.
3
3
⁄
16
81
3
3
⁄
8
85
1
13
⁄
16
47
1
1
⁄
2
38
.82
.37
LFUSG-B-QC-M2
3
⁄
8
" Quick Connect
3
1
⁄
4
83
4
102
2
1
⁄
4
57
1
1
⁄
2
38
1.05
.48
LFUSG-B-QC-SC-M2
3
⁄
8
" Quick Connect
3
1
⁄
4
83
4
102
2
1
⁄
4
57
1
1
⁄
2
38
1.05
.48
Watts
LFUSG-B-M2
NOTE: This information is not intended to replace the full product
installation and safety information available or the experience of a
trained product installer. You are required to thoroughly read all
installation instructions and product safety information before begin-
ning the installation of this product.
