1.1 Instrument description
￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭
2 ￭￭￭￭￭￭￭￭
850 Professional IC –Cation – Prep 1
1
4
6 7 8
2
5
3
9 10 11
Figure 1 Front view of the instrument
1 Conductivity detector
See Chapter 2.17. 2 Injection valve
See Chapter 2.15.
3 Eluent degasser
See Chapter 2.9. 4 High pressure pump
See Chapter 2.10.
5 Peristaltic pump
For sample preparation. See Chapter 2.14. 6 Purge valve
See Chapter 2.10.1.
7 Pulsation damper
See Chapter 2.12. 8 Dialysis cell or ultrafiltration cell
Is not included in the scope of delivery of
the 2.850.1030. Can be ordered as optional
accessories (as individual cell or with equip-
ment).
