1.2 Parts and controls

771 IC Compact Interface

3

11

Mains pilot lamp

Lights up when instrument is

switched on

55

Analog signal connection

22

Mains switch

For switching the instrument on/off

66

Analog signal connection

33

Mains connection plug

Mains connection see

section 2.2

77

Serial number

44

PC connection

RS232 interface
