3 Installation
￭￭￭￭￭￭￭￭ 9
2 Insert the two screws and tighten them.
Figure 7 Tightening the magnetic stirrer
3 Place the previously removed holding mechanism against the main
body and connect the two parts with the three screws.
Figure 8 Screwing on the holding mechanism
4 Mount the mixing vessel and press it all the way down.
NOTE
Observe the recess on the bottom rim of the mixing vessel for
positioning.
It must snap into the main body.
