3.4 Connecting USB devices
￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭
20 ￭￭￭￭￭￭￭￭
856 Conductivity Module
Operation with Touch Control
Connect the barcode reader as follows:
1 Insert the USB plug of the barcode reader into one of the USB sock-
ets of the 856 Conductivity Module.
2 Switch on the Touch Control.
The barcode reader is recognized automatically and entered in the
device manager.
3 Configure the barcode reader in the device manager of the Touch
Control (see Touch Control manual).
Settings on the barcode reader:
Program the barcode reader as follows (see also the manual for the bar-
code reader):
1 Switch the barcode reader to programming mode.
2 Specify the desired layout for the keyboard (USA, Germany, France,
Spain, German-speaking Switzerland).
This setting must match the setting in the device manager (see the
Touch Control manual).
3 Make sure that the barcode reader is set in such a way that Ctrl char-
acters (ASCII 00 to 31) can be sent.
4 Program the barcode reader in such a way that the ASCII character
02 (STX or Ctrl B) is sent as the first character. This first character is
normally referred to as the "Preamble" or "Prefix Code".
5 Program the barcode reader in such a way that the ASCII character
04 (EOT or Ctrl D) is sent as the last character. This last character is
normally referred to as the "Postamble", "Record Suffix" or "Postfix
Code".
6 Exit the programming mode.
