3.2 Installing the rinsing solution flow path
￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭
6
￭￭￭￭￭￭￭￭
IC equipment: Liquid Handling Station
2
￭
Cut off a piece of the capillary that is approx. 50 cm long using
the capillary cutter.
3 Threading the capillary through the bottle holder
￭
Push one end of the capillary (50 cm) through the M6 tubing nip-
ple (1), the O-ring (2) and the M6 opening of the bottle cap (3)
and into the bottle.
￭
Loosely secure the capillary in place using the tubing nipple.
4 Mounting the bottle cap to the supply bottle
￭
Screw the bottle cap onto the supply bottle.
