6.6 Housing
￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭
24 ￭￭￭￭￭￭￭￭
2.896.0010 896 Professional Detector – Conductivity
6.6 Housing
Dimensions
Width 365 mm
Height 131 mm
Depth 380 mm
Material of hous-
ing
Operating ele-
ments
Indicators LED for standby operation
On/Off switch On the rear of the instrument
6.7 Interfaces
USB
Input 1 USB upstream, type B (for connection to the PC)
Output 2 USB downstream, type A
MSB 2 MSB Mini-DIN 8-pin (female) (for Dosino, stirrer, remote lines, ...)
Detector 2 DSUB-15-pin high density (female)
Cell recognition 1 on the front of the instrument
Leak sensor 1 jack plug
Further connec-
tions ￭ 1 DSUB 15-pin (female)
6.8 Safety specifications
This instrument fulfills the following electrical safety requirements:
CE designation in accordance with the EU directives:
￭ 2006/95/EC (Low Voltage Directive, LVD)
￭ 2004/108/EC (EMC Directive, EMC)
Federal Inspectorate for Heavy Current Installations ESTI (Accreditation
Number SCESp 033)
￭ Safety mark for certification type 2 in accordance with NEV (type
testing with market monitoring, EMC conformity)
Design and testing According to EN/IEC 61010-1, UL 61010-1, CSA-C22.2 No. 61010-1,
degree of protection IP20, protection class I.
