©2012 DJI Innovations. All Rights Reserved. 11 |
Ports Description
MC
A Stick operation, for cyclic roll or left/right
E Stick operation, for cyclic pitch or front/back
T Stick operation, for throttle control
R Stick operation, for rudder control
G Switch operation, for gyro sense adjusting
P Stick operation, for collective pitch or up/down
U Switch operation, for Control Mode Switch
X1 For Voltage Monitor (Connect to BEC module)
S1 To #1 swashplate servo
S2 To #2 swashplate servo
S3 To #3 swashplate servo
S4 To #4 swashplate servo
THR To ESC
RUD To rudder servo
F1 Reserved
F2 Reserved
LED LED port, for LED wire connection of LED Module
EXP. GPS port, for GPS module wire connection
LED Module
LED Cable LED cable, to MC ’s LED port
Micro-B USB port: PC connection for configuration and firmware upgrades
BEC Module (Optional)
Switch A 2-position switch which is selection for high-voltage or low-voltage servos, and
provides voltage detection function at the same time.
 7.4V: high-voltage servo
 5.8V: low-voltage servo
BEC Cable To MC X1 port.
Power Supply Cable For battery connection
