15

GLOW UP

Operating Mode

Slave Priority

Repeater

Master Output

Display

Stand Alone / DMX in play/pause

-

Off

-

PLAY (o PAUSE)

-

Wireless to Cable + Repeat &Play

-

PLAYW

C (o PAUSW

C)

-

Cable to Wireless + Repeat & Play

-

PLAYC

W (o PAUSC

W)

-

Wireless to Cable + Repeater only

-

W

C

-

Cable to Wireless + Repeater only

-

C

W

Stand Alone / DMX in stop

Cable

Off

-

DMX C

Wireless

Off

-

DMX W

-

Wireless to Cable + Repeat &Play

-

DMXW

C

-

Cable to Wireless + Repeat &Play

-

DMXC

W

-

Wireless to Cable + Repeater only

-

W

C

-

Cable to Wireless + Repeater only

-

C

W

Master Slave Tx (master addr 1)

-

-

Cable

MAST C

-

-

Wireless

MAST W

-

-

Cable+Wireless

MAST CW

Master Slave Rx (slave addr 1)

Cable

Off

-

SLV C

(Play disabled)

Wireless

Off

-

SLV W

-

Wireless to Cable + Repeat &Play

-

SLV W

C

-

Cable to Wireless + Repeat &Play

-

SLV C

W

-

Wireless to Cable + Repeater only

-

W

C

-

Cable to Wireless + Repeater only

-

C

W

DMX Memory Tx (master all addr)

-

-

Cable

MMTX C

-

-

Wireless

MMTX W

-

-

Cable+Wireless

MMTX CW

DMX Memory Rx (slave addr N)

Cable

Off

-

MMRX C

(Play disabled)

Wireless

Off

-

MMRX W

-

Wireless to Cable + Repeat &Play

-

MMRX W

C

-

Cable to Wireless + Repeat &Play

-

MMRX C

W

-

Wireless to Cable + Repeater only

-

W

C

-

Cable to Wireless + Repeater only

-

C

W

"Repeater"-> "Function"->"Repeat & Play"
"Repeater"-> "Direction"->"Wirel. to Cable"
‘’DMX address’’ = 1
"Display"-> Off
“Contrast” = 5
“MOD”-> "Stand Alone/DMX"
"Slave Priority"-> "Cable"

CPU RESET
Used to reset the CPU. Settings will not be reset.
1) Press ENTER

A

– a confirmation message appears on the display

(OK?)

2) Press ENTER

A

to RESET or SELECT

S

to return to the previous

Menu.

TEST
Used to test the correct operations of effects.
1) Press ENTER

A

.

2) Use the

B

and DOWN

C

keys to select the Test function.

3) Press ENTER

A

to confirm the select and start the TEST or SELECT

S

to keep current settings.

CPU

Reset

Test

Advanced

Reset

OPERATING MODES

NOTE: the Wireless board is not two-way, therefore the following functions are excluded:
1) Repeater from Wireless to Wireless.
2) Receiving and transmitting wireless at the same time.
