12

GLOW UP

MODE
Assigns the desired command to the GlowUP Radio module
1) Press ENTER

A

– current settings appear on the display.

2) Use the UP

B

and DOWN

C

keys to select one of the following settings:

SLAVE PRIORITY: GlowUp runs as a Slave
Press ENTER

A

and use the UP

B

and DOWN

C

keys to select

the DMX signal reception priority in case of conflict between the cable
and wireless signals
Cable (default)
Wireless
Press ENTER

A

to confirm the selection (the display blinks for

several seconds) or SELECT

S

to keep the current settings and

return to the previous Menu.

MASTER OUTPUT: GlowUp runs as a Master
Press ENTER

A

and use the UP

B

and DOWN

C

keys to select

how the DMX signal should be sent to other devices:
Cable+Wireless
Cable
Wireless
Press ENTER

A

to confirm the selection (the display blinks for

several seconds) or SELECT

S

to keep the current settings and

return to the previous Menu.

REPEATER: GlowUp runs as a repeater
Press ENTER

A

and use the UP

B

and DOWN

C

keys to select

how to run GlowUP as a repeater: :
Direction – Press ENTER

A

again and use the UP

B

and DOWN

C

keys to select whether the repeater should transmit the DMX signal from:
-Wireless to Cable
-Cable to Wireless
Press ENTER

A

to confirm the selection (the display blinks for

several seconds) or SELECT

S

to keep the current settings and

return to the previous Menu.

Function– Press ENTER

A

again and use the UP

B

and DOWN

C

keys to select whether the repeater should run from:

- Repeat & Play (GlowUp repeats and plays)
- Repeat Only (GlowUp operates in repeat mode only)
Press ENTER

A

to confirm the selection (the display blinks for

several seconds) or SELECT

S

to keep the current settings and

return to the previous Menu.

To enable the REPEATER function, operate Enable or Disable.
Enable/Disable
Press ENTER

A

to confirm the selection (the display blinks for

several seconds) or SELECT

S

to keep the current settings and

return to the previous Menu.

LOCK OPTION
It lets you assign a lock password, requested at each projector start up.
The same password can be used to access the "Menu Advanced".
1) Press ENTER

A

and access the Lock menu to enable ON or disable

OFF the password request at start up.
- Select ON to enable. The previously entered password is displayed

and the desired numerical password can be entered with the UP

B

e DOWN

C

and ENTER

A

keys.

- By selecting OFF, no password will be requested at projector start up.

2) Access the Set Password menu and use the UP

B

, DOWN

C

and

ENTER

A

keys to assign the desired Password number.

DISPLAY
Allows you to dim the display backlight 60 seconds after switching to idle
status. To turn it back on, simply press any key.
1) Press ENTER

A

– current settings appear on the display.

2) Use the UP

B

and DOWN

C

keys to turn display backlight OFF or ON.

3) Press ENTER

A

to confirm the selection (the display blinks for

several seconds) or SELECT

S

to keep the current settings and

return to the previous Menu.

Display

Lock

Option

Mode

Advanced

Setup
