ASSEMBLED PARTS
Fasteners Shown Actual Size
For your convenience, we included extra fasteners!
Note: Tighten and loosen all screws with a Phillips
screwdriver. Do not over-tighten the screws.
12 Volt Charger
12 Volt Battery
Hood Latch – 2
Light Cover – 2
Spacer - 2
Key Assembly
Steering Column Cap
#8 - 32 x 1
5
/
8
" Screw – 2
#8 Acorn Lock Nut – 2
#8 x 3" Screw – 2
#10 x
3
/
4
" Screw – 23
5
/
32
"x 1
1
/
2
" Pin – 1
