9
rAPid FlOW inSTAllATiOn
rapid Flow exhaust # 83222
9. Install the Y Pipe Muffler by hanging the Y pipe from
Hanger D. You will need two clamps to secure both the
Passenger Side Tail Pipe and the Driver Side Tail Pipe. The
Y Pipe will need to be installed vertically. The Passenger
Side Tail Pipe is fitted into the lower extension and the
Driver Side Tail Pipe will be in the upper extension as
shown.
10. Install the Passenger Side Tail Pipe over the rear axle.
Confirm that the bend of the Passenger Side Tail Pipe is
directly over the rear axle.
11. Install the Passenger Side Tail Pipe Tip into the Pas-
senger Side Tail Pipe. Use one of the supplied clamps to
secure the junction between the two pipes.
12. Install the Driver Side Tail Pipe over the rear axle. Again
confirm that the bend of the Driver Side Tail Pipe is di-
rectly over the rear axle.
13.Install the Driver Side tail Pipe Tip into the Driver Side Tail
Pipe. Use one of the supplied clamps to secure the junc-
tion between the two pipes .
Hanger D
Driver Side Tail Pipe
Passenger Side Tail Pipe
Driver Side Tail Pipe
SwITCH DIRECTIONS: THE NEXT STEPS wILL BE FROM THE BACk OF THE TRUCk
