KONTROL 5 Skywire Manual Rev. A
Copyright © 2013 Blizzard Lighting, LLC
2. INTRODUCTION
2.1 Features
•
DMX512/1990 Standard
•
2.4Ghz built-in wireless DMX transmitter
•
512 auto-assigning frequencies in 7 groups
•
16 preset scene/color banks, 8 per page
•
Record up to 16 chases with up to 200 scenes per chase
•
5 sliders for direct control of channels
•
Built-in microphone for music mode
•
Auto mode program controlled by fade time sliders
•
DMX out: 3-pin XLR
•
LED information display
•
Blackout function and instant strobe with variable speed fader
•
USB Backup/Restore of Data
2.2
General Overview
The controller is a universal intelligent lighting controller. It allows the con-
trol of 16 fixtures composed of 10 channels each and up to 16 program-
mable scenes. Sixteen chase banks can contain up to 200 steps composed
of saved scenes or manual inputs in any order. Programs can be triggered
by music, automatically or manually. All chases can be executed at the
same time.
On the surface you will find various programming tools such as 5 RGBAW/
universal channel sliders, quick access fixture and scene buttons, and an
LED display indicator for easier navigation of controls and menu functions.
2.3 Nifty, Spiffy Diagram (front)
1
2
3
4
5
6
7
8
9
11
12
16
17
18
13
14
20
10
19
15
