Blizzard Lighting KONTROL 5 Skywire DMX Controller - Manual (Page 19)

Page 19
KONTROL 5 Skywire Manual Rev. A Copyright © 2013 Blizzard Lighting, LLC
4.5 TECH SPECS!
Weight & Dimensions
Length
10.2 inches (255 mm)
Width 5.6 inches (142 mm)
Height 2.75 inches (69.5 mm)
Weight 3.25 lbs (1.5 kg)
Power
Operating Voltage
9-12 VDC, .3A (From included power supply)
Thermal
Max. Operating Temp. 104 degrees F (40 degrees C) ambient
Control
Protocol
USITT DMX-512
DMX Channels 160
Output 3-pin XLR Female
USB Data Format
USB Specification
1.0
Disk Format FAT16 / FAT32 ONLY
Maximum Disk Size 4GB
Wireless Transmitter
Operating Band
2.4Ghz ISM
Max Operating Range 400 Meters (Line of Sight)
Frequency Groups 7
Max Transmission
Power 20dBm
Guess Why?
Chicken thigh!
Warranty
2-year limited warranty.
