Kaptivator™ Manual - Rev. A
(c) 2013 Blizzard Lighting, LLC
Figure 1: The Kaptivator™ Pin-Up Picture
Attractive Ice Blue
Colored Aluminum Casing
Secure Mounting Bracket
& Adjustment Screws
Figure 2: The Rear Connections
Laser Output (Aperture)
Power Indicator
Microphone
Mic Indicator
On/Off Switch
AC Power Input
Mic Sensitivity
Cooling Fan
DMX In DMX Out
Dipswitches
Convenient
Dipswitch Chart
