2. MEET THE KApTIvATOR™
MAIN FEATURES
• High power class 3B RGB laser
• Sound active mode, auto mode, DMX512 (11ch) & master/slave
• 120 beam show and 7 animated graphic show patterns
• 3-pin DMX In/Out
• Microphone sensitivity adjustment knob
• Dipswitch contolled function settings
• Polished blue aluminum casing w/hanging bracket
• Compact and lightweight (it kept its new year’s resolution!)
Laser Specifications
Color Wavelength Power Output
Red 650nm 100mW
Green 532nm 50mW
Blue 450nm 100mW
White (all) 250mW
DMX Quick Reference - 11 Channel Mode
Channel What it does
1
Mode
2 Pattern Select
3 Color Change
4 Moving-X
5 Moving-Y
6 Dimmer-X
7 Dimmer-Y
8 Rotation
9 Zoom (+/-)
10 Drawing
11 Rolling X/Y
