Blizzard Lighting Kaptivator RGB 3D Laser - Manual (Page 15)

Page 15
Kaptivator™ Manual - Rev. A (c) 2013 Blizzard Lighting, LLC
Tech Specs!
Weight & Dimensions
Length
10.25 inches (26.04 cm)
Width 8 inches (20.32 mm)
Height 4 inches (10.16 mm)
Weight 5.45 lbs (2.46 kg)
Power
Operating Voltage
100-240VAC, 50-60 Hertz
Fuse 2A 250V
Power Consumption 50W
Light Source
Laser
Color Wavelength Power Output
Red 650nm 100mW
Green 532nm 50mW
Blue 450nm 100mW
White (all) 250mW
Thermal
Max. Operating Temp.
104 degrees F (40 degrees C) ambient
Control
Protocol
USITT DMX-512
DMX Channels 11 Channel
Input 3-pin XLR Male
Output 3-pin XLR Female
Other Operating Modes Standalone, Master/Slave, Sound Active
Coolness Factor
Leventy Billion Percent
Warranty
2-year limited warranty, does not cover malfunction
caused by damage to LED’s.
