ToughPar Satellight Manual Rev. A © 2014 Blizzard Lighting, LLC
Control Panel Menu Structure
001 001 - 512
To choose the DMX address
PSA
Sets the fixture to run in slave mode
PA - PA5 - PA9
To choose 5 or 9 channel DMX mode
Pd - Pd0 - Pd4
To choose 32-bit dimming mode 0-4
P0 - P00 - P09
Red intensity from 0-9 (0% <--> 100%)
P1 - P10 - P19
Blue intensity from 0-9 (0% <--> 100%)
P2 - P20 - P29
Green intensity from 0-9 (0% <--> 100%)
P3 - P30 - P39
White intensity from 0-9 (0% <--> 100%)
P4 - P40 - P49
Strobe intensity from 0-9 (slow <--> fast)
P5 - P50 - P59
Color jump, speed 0-9 (slow <--> fast)
P6 - P60 - P69
Color fade, speed 0-9 (slow <--> fast)
