Motif Fresco™ Manual Rev. A Copyright (c) 2014 Blizzard Lighting, LLC
Control Panel Menu Structure
Note: The menu will automatically LOCK after 10 seconds of inactivity.
To unlock the menu, press and hold + for 2 seconds.
d001 d001 - d512
To choose the DMX address
3-CH
To choose 3 channel DMX mode
5-CH
To choose 5 channel DMX mode
7-CH
To choose 7 channel DMX mode
SLAu
Sets the fixture to run in slave mode
Colr r000-r255
Red Intensity (0% <--> 100%)
9000-925
Green Intensity (0% <--> 100%)
b000-b255
Blue Intensity (0% <--> 100%)
Pr-- Pr01 - Pr07
Static colors (1), Programs (2-7)
SP01 - SPFL
Speed adjustment (slow <--> fast)
FS 00 - F599
Strobe speed (slow <--> fast)
Auto mode
DMX Mode
Allows the unit to be controlled by any universal DMX controller.
1.) The default mode for the fixture is DMX, which appears as d001 on the LED read-
out. To select a different DMX address, hit the button and use the
DOWN> buttons to select the your desired starting DMX address ranging from d001 -
d512, then hit again to confirm your choice.
2.) You can now use the buttons to scroll through your choices of 3-ch,
5-ch, or 7ch. Press to confirm your choice.
Slave Mode
1.) To use as a slave unit, simply use the button to scroll to SLAu. This
fixture will now be in slave mode and follow the master unit, which is the fixture in the
DMX chain.
