Torrent™ Streak User Manual - Rev. A (c) 2014 Blizzard Lighting, LLC
2. MEET THE TORRENT STREAK™
MAIN FEATURES
• 1x Luminus CBT-140 75W LED, 6500K light source
• Ultra-narrow, sharp 2 degree beam angle
• 3-phase pan/tilt motors with 8/16-bit resolution
• Switchable 540/630 degree pan and 270 degree tilt
• Static gobo wheel with 11 gobos
• Color wheel: 11 colors (including UV) + open
• Variable direction rainbow effects with adjustable speeds
• Electronic dimmer and focus
• 8-facet prism with variable speed and direction
• Motorized linear iris with pulse/burst functions
• Variable linear frost filter
• 0-100% 16-bit electronic dimmer
• 0-20Hz strobe w/random, pulse in/pulse out functions
• 13/11/13/15 channel modes including custom design mode
• 8 easy-to-use built-in programs
• LCD-based menu system
• DMX recorder/editor built-in for standalone operation
• Variable speed cooling fans with smart LED protection
• ¼-turn “omega” style clamp brackets
• POWERCON-compatible power in/out
CONTROL:
• USITT DMX-512 (13/11/13/15 Channels)
• 3-pin Input/Output
• 4-button menu with blue background LCD display
DMX Quick Reference
Ch. Vector Mode (15ch) 16-Bit Mode (13ch) 8-Bit Mode (11ch) Design Mode (13ch)
1 Pan Pan Pan Pan
2 Pan Fine Pan Fine Tilt Pan Fine
3 Tilt Tilt Color Wheel Tilt
4 Tilt Fine Tilt Fine Gobo Wheel Tilt Fine
5 Color Wheel Color Wheel Strobe Color Wheel
6 Gobo Wheel Gobo Wheel Dimmer Gobo Wheel
7 Shutter/Strobe Shutter/Strobe Focus Shutter/Strobe
8 Dimmer Dimmer Prism Dimmer
9 Focus Focus Frost Focus
10 Prism Prism Pan/Tilt Speed Prism
11 Frost Frost Built-In Programs Frost
12 Pan/Tilt Speed Pan/Tilt Speed --- Pan/Tilt Speed
13 Built-In Programs Built-In Programs --- Built-In Programs
14 Color Time --- --- ---
15 Gobo Time --- --- ---
