Torrent™ Streak User Manual - Rev. A (c) 2014 Blizzard Lighting, LLC
Control Panel Menu Structure
Main Function Sub Function Selection What It Does...
Function Mode
1
1. DMX Address A001 <-> A255 Sets the DMX address
2. Set To Slave Run fixture in slave mode
3. Auto Run = Master
= Alone
Run auto program 1-8
4. Music Control = Master
= Alone
Run sound active program 1-8
Reset
2
N/A = OFF / =ON Resets the fixture.
Reverse Pan
3
N/A = OFF / =ON Reverses the fixture’s Pan movement
Reverse Tilt
4
N/A = OFF / =ON Reverses the fixture’s Tilt movement
Mic Sensitivity
5
N/A 000% <-> 100% Adjusts the sensitivity of the fixture’s internal micro-
phone.
Special
6
1. Reset Default = OFF / =ON Resets all programmable settings to factory default
settings.
2. Calibration Code
= 000 <-> 255
Lockout code for fixture calibration. (code: 088)
PAN
= 000 <-> 255
Adjusts the zero point for each setting to account for
subtle variations from fixture to fixture, or in case
recalibration becomes necessary.
Each fixture is calibrated at the factory and
under normal operating conditions these settings
should not require adjustment.
TILT
= 000 <-> 255
Color Wheel
= 000 <-> 255
Gobo Wheel
= 000 <-> 255
Dimmer
= 000 <-> 255
Focus
= 000 <-> 255
Prism
= 000 <-> 255
Frost
= 000 <-> 255
3. Temperature = XXXC Displays the internal temperature at the light source.
4. Manual Control PAN
Allows you to manually set the fixture to a fixed setting
using the DMX values for each channel. For more
information on DMX values available for each channel,
see pages 14-15.
PAN-Fine
TILT
TILT-Fine
Move Speed
Color Wheel
Gobo Wheel
Gobo Rotation
Strobe
Dimmer
Focus
Prism
Iris
Zoom
Frost
5. Signal Set = Wire DMX
= Wireless DMX
= Act WDMX & Out
Sets the DMX signal type.
