Torrent™ Streak User Manual - Rev. A

Control Panel Menu Structure (Continued)

Main Function

Sub Function

Selection

What It Does...

Edit Program

Program 1 - Program 8

Steps

000 <-> 048

Selects the number of active steps in the cur-

rent program (Auto or Program 1 - 8)

Scenes

000 <-> 048

Selects the scene for editing

PAN

Allows you to edit the pre-programmed “Auto

Program” which the fixture uses in Auto and

Sound active Modes using the DMX values

for each channel, or edit one of 8 built in

programs which are available using DMX

channel #15.

For more information on DMX values available

for each channel, see pages 14-15.

PAN-Fine

TILT

TILT-Fine

Move Speed

Color Wheel

Gobo Wheel 1

Gobo Rotation

Strobe

Dimmer

Focus

Prism

Iris

Zoom

Frost

Scene Time

Mode of Channel

n/a

16Bit Mode

8Bit Mode

Vector Mode

Design Mode

13ch DMX mode

11ch DMX mode

15ch mode w/color & gobo speed adjustments

13ch custom DMX mode
