Torrent™ Streak User Manual - Rev. A
(c) 2014 Blizzard Lighting, LLC
DMX Channel Value
Vector
Mode
16-bit
Mode
8-bit
Mode
Design
Mode
Ch. Value
What it does
1
1
1
1
000 <-> 255 Pan
2
2
2
000 <-> 255 Pan Fine (16-Bit Pan)
3
3
2
3
000 <-> 255 Tilt
4
4
4
000 <-> 255 Tilt Fine (16-Bit Tilt)
5
5
3
5
000 <-> 004
005 <-> 009
010 <-> 014
015 <-> 019
020 <-> 024
025 <-> 029
030 <-> 034
035 <-> 039
040 <-> 044
045 <-> 049
050 <-> 054
055 <-> 059
060 <-> 064
065 <-> 069
070 <-> 074
075 <-> 079
080 <-> 084
085 <-> 089
090 <-> 094
095 <-> 099
100 <-> 104
105 <-> 109
110 <-> 114
115 <-> 127
128 <-> 189
190 <-> 193
194 <-> 255
Color Wheel
Open
White + Color 1
Color 1
Color 1 + Color 2
Color 2
Color 2 + Color 3
Color 3
Color 3 + Color 4
Color 4
Color 4 + Color 5
Color 5
Color 5 + Color 6
Color 6
Color 6 + Color 7
Color 7
Color 7 + Color 8
Color 8
Color 8 + Color 9
Color 9
Color 9 + Color 10
Color 10
Color 10 + Color 11
Color 11
Color 11 + White
Color Wheel Scroll (Clockwise, Fast <-> Slow)
Stop
Color Wheel Scroll (CCW, Slow <-> Fast)
6
6
4
6
000 <-> 008
009 <-> 017
018 <-> 026
027 <-> 035
036 <-> 044
045 <-> 053
054 <-> 062
063 <-> 071
072 <-> 080
081 <-> 089
090 <-> 098
099 <-> 107
108 <-> 116
117 <-> 125
126 <-> 134
135 <-> 143
144 <-> 152
153 <-> 161
162 <-> 170
171 <-> 179
180 <-> 188
189 <-> 197
198 <-> 206
207 <-> 255
Gobo Wheel
Open
Gobo 1
Gobo 2
Gobo 3
Gobo 4
Gobo 5
Gobo 6
Gobo 7
Gobo 8
Gobo 9
Gobo 10
Gobo 11
Gobo Shake 01 (Slow <-> Fast)
Gobo Shake 02 (Slow <-> Fast)
Gobo Shake 03 (Slow <-> Fast)
Gobo Shake 04 (Slow <-> Fast)
Gobo Shake 05 (Slow <-> Fast)
Gobo Shake 06 (Slow <-> Fast)
Gobo Shake 07 (Slow <-> Fast)
Gobo Shake 08 (Slow <-> Fast)
Gobo Shake 09 (Slow <-> Fast)
Gobo Shake 10 (Slow <-> Fast)
Gobo Shake 11 (Slow <-> Fast)
Gobo Wheel Spin (Slow <-> Fast)
7
7
5
7
000 <-> 031
032 <-> 063
064 <-> 095
096 <-> 127
128 <-> 159
160 <-> 191
192 <-> 223
224 <-> 255
Strobe
Closed
Open
Strobe (Slow <-> Fast)
Open
Pulse Strobe (Slow <-> Fast)
Open
Random Strobe (Slow <-> Fast)
Open
