Torrent™ Streak User Manual - Rev. A
(c) 2014 Blizzard Lighting, LLC
DMX Channel Value (Continued)
Vector
Mode
16-bit
Mode
8-bit
Mode
Design
Mode
Ch. Value
What it does
8
8
6
8
000 <-> 255
Dimmer
0 <-> 100%
9
9
7
9
000 <-> 255
Focus
Near <-> Far
10
10
8
10
000 <-> 005
006 <-> 127
128 <-> 189
190 <-> 193
194 <-> 255
Prism
OFF
ON
Forwards rotation from fast to slow
Prism rotation stop
Backwards rotation from slow to fast
11
11
9
11
000 <-> 199
200 <-> 255
Frost
Frost In
Frost Out
12
12
10
12
000 <-> 225
226 <-> 235
236 <-> 245
246 <-> 255
Pan/Tilt Speed
Fast <-> Slow
Blackout by movement
Blackout by all wheel change
No function
13
13
11
13
000 <-> 079
080 <-> 099
100 <-> 119
120 <-> 139
140 <-> 159
160 <-> 179
180 <-> 199
200 <-> 219
220 <-> 239
240 <-> 255
Control (Hold Each for 5 Seconds to Set)
No Function
Motor Reset
Built-In Program #1
Built-In Program #2
Built-In Program #3
Built-In Program #4
Built-In Program #5
Built-In Program #6
Built-In Program #7
Built-In Program #8
14
---
---
---
000 <-> 255
Color Time
Fast <-> Slow
15
---
---
---
000 <-> 255
Gobo Time
Fast <-> Slow
