HighBeam™ Manual Rev. A
© 2013 Blizzard Lighting, LLC
Figure 1: The HighBeam™ Pin-Up Picture
High Power OSRAM 4-in-1
Quad Color LEDs
Dual Mounting Yokes &
Adjustment/Locking Knobs
Figure 2: Behind The Beam
AC Power Out
DMX In
DMX Out
Menu Buttons
AC Power In
LED Display
High Tech Space Age
Polymer Housing
