HighBeam™ Manual Rev. A © 2013 Blizzard Lighting, LLC
2. MEET THE HIGHBEAM™ LED PAR
CONTROL FEATURES
• color mixing and 3-zone pixel control via 7 15W OSRAM Red/Green/
Blue/White 4-in-1 LEDs
• Variable electronic dimming & strobe
• Built-in color & chase macros via DMX
• Built-in automated programs via master/slave
• Built-in sound active programs
• RGBW color mixing ability in standalone mode
• RGBW (4-Ch), RGBW + Dimmer (5-Ch), Pixel Mode (16-Ch), &
Enhanced Pixel Mode (20-Ch) DMX Profiles
ADDITIONAL FEATURES
• Housed in Heavy Duty Space Age Polymers
• Super-quiet variable-speed internal Fan Cooling
• Dual mounting brackets for positioning flexibility
• Flicker-free constant-current 400hz LED driver
• 3-pin male input and 3-pin female output
• PowerCon™ compatible AC power In/Out connectors
DMX Quick Reference - 16 / 20 Channel Mode
Ch 16 Channel 20 Channel Ch 16 Channel 20 Channel
1
R1 Intensity Dimmer 11 B3 Intensity G3 Intensity
2 G1 Intensity R1 Intensity 12 W3 Intensity B3 Intensity
3 B1 Intensity G1 Intensity 13 R4 Intensity W3 Intensity
4 W1 Intensity B1 Intensity 14 G4 Intensity R4 Intensity
5 R2 Intensity W1 Intensity 15 B4 Intensity G4 Intensity
6 G2 Intensity R2 Intensity 16 W4 Intensity B4 Intensity
7 B2 Intensity G2 Intensity 17 --- W4 Intensity
8 W2 Intensity B2 Intensity 18 --- Strobe Speed
9 R3 Intensity W2 Intensity 19 --- Built in Macros
10 G3 Intensity R3 Intensity 20 --- 32-Bit Dimmer
DMX Quick Reference - 4 (RGBW) / 5 (D/RGBW) Channel Mode
Channel 4 Channel 5 Channel
1 Red Intensity Dimmer
2 Green Intensity Red Intensity
3 Blue Intensity Green Intensity
4 White Intensity Blue Intensity
5 --- White Intensity
