HighBeam™ Manual Rev. A
© 2013 Blizzard Lighting, LLC
DMX Values In-Depth 16-Channel Mode (Pixel Mode)
Channel
Value
What It Does
1
000 <--> 255
Red 1 Intensity (0% <--> 100%)
2
000 <--> 255
Green 1 Intensity (0% <--> 100%)
3
000 <--> 255
Blue 1 Intensity (0% <--> 100%)
4
000 <--> 255
White 1 Intensity (0% <--> 100%)
5
000 <--> 255
Red 2 Intensity (0% <--> 100%)
6
000 <--> 255
Green 2 Intensity (0% <--> 100%)
7
000 <--> 255
Blue 2 Intensity (0% <--> 100%)
8
000 <--> 255
White 2 Intensity (0% <--> 100%)
9
000 <--> 255
Red 3 Intensity (0% <--> 100%)
10
000 <--> 255
Green 3 Intensity (0% <--> 100%)
11
000 <--> 255
Blue 3 Intensity (0% <--> 100%)
12
000 <--> 255
White 3 Intensity (0% <--> 100%)
13
000 <--> 255
Red 4 Intensity (0% <--> 100%)
14
000 <--> 255
Green 3 Intensity (0% <--> 100%)
15
000 <--> 255
Blue 4 Intensity (0% <--> 100%)
16
000 <--> 255
White 4 Intensity (0% <--> 100%)
DMX Values In-Depth 5-Channel Mode
Ch.
Value
What It Does
1
000 <--> 255
Dimmer (0% <--> 100%)
2
000 <--> 255
Red Intensity (0% <--> 100%)
3
000 <--> 255
Green Intensity (0% <--> 100%)
4
000 <--> 255
Blue Intensity (0% <--> 100%)
5
000 <--> 255
White Intensity (0% <--> 100%)
DMX Values In-Depth 4-Channel Mode
Ch.
Value
What It Does
1
000 <--> 255
Red Intensity (0% <--> 100%)
2
000 <--> 255
Green Intensity (0% <--> 100%)
3
000 <--> 255
Blue Intensity (0% <--> 100%)
4
000 <--> 255
White Intensity (0% <--> 100%)
