HighBeam™ Manual Rev. A © 2013 Blizzard Lighting, LLC
DMX Values In-Depth 20-Channel Mode (Enhanced Pixel Mode)
Channel Value What It Does
1 000 <--> 255 Dimmer (0% <--> 100%)
2 000 <--> 255 Red 1 Intensity (0% <--> 100%)
3 000 <--> 255 Green 1 Intensity (0% <--> 100%)
4 000 <--> 255 Blue 1 Intensity (0% <--> 100%)
5 000 <--> 255 White 1 Intensity (0% <--> 100%)
6 000 <--> 255 Red 2 Intensity (0% <--> 100%)
7 000 <--> 255 Green 2 Intensity (0% <--> 100%)
8 000 <--> 255 Blue 2 Intensity (0% <--> 100%)
9 000 <--> 255 White 2 Intensity (0% <--> 100%)
10 000 <--> 255 Red 3 Intensity (0% <--> 100%)
11 000 <--> 255 Green 3 Intensity (0% <--> 100%)
12 000 <--> 255 Blue 3 Intensity (0% <--> 100%)
13 000 <--> 255 White 3 Intensity (0% <--> 100%)
14 000 <--> 255 Red 4 Intensity (0% <--> 100%)
15 000 <--> 255 Green 3 Intensity (0% <--> 100%)
16 000 <--> 255 Blue 4 Intensity (0% <--> 100%)
17 000 <--> 255 White 4 Intensity (0% <--> 100%)
18 000 <--> 010
011 <--> 255
Strobe Off
Strobe (Slow <--> Fast)
19
000 <--> 020
021 <--> 030
031 <--> 040
041 <--> 050
051 <--> 060
061 <--> 070
071 <--> 080
081 <--> 090
091 <--> 100
101 <--> 110
111 <--> 120
121 <--> 130
131 <--> 140
141 <--> 150
151 <--> 160
161 <--> 170
171 <--> 180
181 <--> 190
191 <--> 063
201 <--> 210
211 <--> 220
221 <--> 255
Fade, Color Change, Sound Active
No Function
Red
Green
Blue
White
Red + Green
Red + Blue
Red + White
Green + Blue
Green + White
Blue White
Red + Green + Blue
Red + Green + White
Red + Blue + White
Green + Blue + White
Red + Green + Blue +White
Macro 1
Macro 2
Macro 3
Macro 4
Macro 5
Sound Active
20
000 <--> 005
006 <--> 055
056 <--> 105
106 <--> 155
156 <--> 205
206 <--> 255
32 Bit Dimmer
As set in the control menu display
Mode 0 = 8-bit, 256 dimming steps
Mode 1 = 32-bit, 0-25% intensity range
Mode 2 = 32-bit, 0-50% intensity range
Mode 3 = 32-bit, 0-75% intensity range
Mode 4 = 32-bit, full intensity dimming
