VIP System

PARAMETER SPECIFICATIONS

Frequency Range 307 kHz - 150 MHz (Sensor Dependent)

Frequency Resolution 100 Hz

Frequency Accuracy ± 1 kHz

Harmonics 10 maximum, up to 150 MHz (Sensor Dependent)

Number of fundamentals (F0) Maximum of 3 simultaneously

Digital > Voltage, current, phase, frequency, impedance, power at frequencies selected by user

Analog 5 Outputs, 0-10Vdc, 1000Ω-source

Update Rates 60 Hz typical for 1 fundamental (Note 1)

Network Protocol DeviceNet, Ethernet

RF Power, Max 10 kW or maximum power limit of RF connector

RF Connector Custom or QC

Receiver Operating +20 to +40 °C (68 to 104 °F)

Receiver Storage -20 to +80 °C (-4 to +176 °F)

Cable Operating 0 to +100 °C (32 to 212 °F)

Cable Storage -20 to +100 °C (-4 to 212 °F)

Sensor Operating/Storage Refer to Sensor Specification

Humidity, Max 85% Non-condensing

Air Pressure, min 745 mbar (equivalent to 2,500 m / 8,200 ft. max altitude)

Operating Power 11-24 Vdc, 1.4-3A input to receiver

PARAMETER

VOLTAGE

CURRENT

PHASE ANGLE

Measurement

RF: 1 to 3000Vrms (Note 2)

0.1 to 100 Arms (Note 2)

-180° to + 180°

Resolution

IEEE 754 Single Precision Floating Point

Uncertainty 307 kHz-1 MHz

(Note 3)

for F

, ± 0.5 V or 1% of reading

whichever is greater for F

, ± 0.1 V or

2% of reading, whichever is greater
(95% confidence intreval)

for F

, ± 0.05 A or 1% of reading

whichever is greater for F

, ± 0.10 A

or 2% of reading, whichever is greater

(95% confidence intreval)

Absolute Angle:
for F

≥ 10 V, 1A:, ±1°

for F

< 10 V, 1A:, ±4°

for F

≥ 10 V, 1A:, ±2°

for F

< 10 V, 1A:, ±6°

(95% confidence intreval)

Uncertainty 1-100 MHz (Note 3)

for F

, ± 0.1 V or 1% of reading

whichever is greater for F

, ± 0.2 V or

2% of reading, whichever is greater
(95% confidence intreval)

for F

, ± 0.01A or 1% of reading

whichever is greater for F

, ± 0.02 A

or 2% of reading, whichever is greater

(95% confidence intreval)

Absolute Angle:
for F

≥ 10 V, 1A:, ±1°

for F

< 10 V, 1A:, ±4°

for F

≥ 10 V, 1A:, ±2°

for F

< 10 V, 1A:, ±6°

(95% confidence intreval)

Uncertainty 100-150 MHz

(Note 3)

for F

, ± 0.2 V or 2% of reading

whichever is greater for F

, ± 0.4 V or

4% of reading, whichever is greater
(95% confidence intreval)

for F

, ± 0.02 A or 2% of reading

whichever is greater for F

, ± 0.04 A

or 4% of reading, whichever is greater
(95% confidence intreval)

Absolute Angle:
for F

≥ 10 V, 1A:, ±2°

for F

< 10 V, 1A:, ±8°

for F

≥ 10 V, 1A:, ±4°

for F

< 10 V, 1A:, ±12°

(95% confidence intreval)

Receiver Temperature

Derating - From 25 °C

± 0.05% / °C

± 0.1% / °C

30303 Aurora Rd.

Solon, OH 44139

866.695.4569

www.bird-technologies.com

Note 1: Typical data rate for 1 fundamental, 10 harmonics, auto-ADC mode, and no averaging is 60 Hz. Data rate can vary significantly depending
on configuration, network traffic, and host performance.
Note 2: Maximum power is limited by the size of the sensor line section and connectors. See sensor specification document.
Note 3: At customer specified frequencies.
