26
Specifications
Frequency Range (Element
Dependent) 2 MHz – 2.3 GHz
Power Range (Element
Dependent) 1 W – 1 kW
Impedance, Nominal 50 ohms
VSWR, Insertion 1.05:1 max 2 MHz – 1 GHz
Accuracy
10° to 35°C
–20° to +50°C
± 4% of reading ± 1% of full scale
± 6% of reading ± 2% of full scale
Peak/Average Ratio > 10 dB
Settling Time < 1 s
Meter Shock mounted linear scale with
expanded scales of 25, 50 and 100 full
scale. Includes 5% overrange.
Connectors Bird “QC” N Female normally supplied
Battery Standard 9V battery. 200 hours
operation, minimum.
Operating Position Any
EMC Complies with 89/336/EEC and 92/31/
EEC
Emissions Immunity Safety EN 55011:1991 Class B
EN 50082-2:1995
EN 61010-1:1993 in accordance with
79/23/EEC and 93/68/EEC
Complies with IEC-1010-1,
UL-1244, and CSA-231
Temperature, Operating –4 to +122 °F (–20 to +50 °C)
Temperature, Storage –13 to +149 °F (–25 to +65 °C)
Humidity 90% noncondensing max
Dimensions (Nominal) 3-5/8”L x 4”W x 6-7/8”H
(92 x 102 x 175 mm)
Weight (Approx.) 4 lb. (1.8 kg) with N-Connectors
Finish Black Powder Coat
