Specifications
Replacement Parts
Frequency Range 25 – 1000 MHz
Power Rating 500 W, 25 – 800 MHz
150 W, 800 – 1000 MHz
Power Range Settings 5/15/50/150/500 W
Insertion VSWR (Max.)
UHF Connnector
N Connector
1.08, 25 – 512 MHz
1.12, 512 – 1000 MHz
1.05, 25 – 512 MHz
1.07, 512 – 1000 MHz
Insertion Loss (Max.)
UHF Connnector
N Connector
0.1 dB, 25 – 512 MHz
0.15 dB, 512 – 1000 MHz
0.1 dB, 25 – 512 MHz
0.13 dB, 512 – 1000 MHz
Accuracy
25 – 100 MHz
100 – 512 MHz
512 – 1000 MHz
± 7% of full scale (with correction
factor)
± 6% of full scale
± 7% of full scale
Impedance, Nominal 50 Ω
Connectors Bird “QC”, Female, N or UHF, normally
supplied
Operating Position Any
Dimensions (Nominal) 3-5/8”L x 4”W x 6-7/8”H
(92 x 102 x 175 mm)
Approximate Weight 4 lb. (1.8 kg) with N-Connectors
Finish Grey Powder Coat
Description Qty. Part Number
Housing Assembly 1 4410-003
Cover Assembly 1 4304-069
Line Section Assembly 1 4304-067
Carrying Strap 1 8580A003
Microammeter 1 2120-015
Shock Mount 1 4220-087
Shock Ring 1 4410A261
Gasket 1 5-1066
Range Switch Knob 1 5-1852
Rubber Feet 4 5-1388
