3
Chapter 2 Setup
This chapter provides information for on-site requirements, unpacking,
inspection, and preparing the Bird High Power Cal Cart for use.
Unpacking and Inspection
1. Carefully inspect shipping container for signs of damage.
2. Do one of the following:
z If the shipping container is damaged, do not unpack the unit. Immedi-
ately notify the shipping carrier and Bird Electronic Corporation.
z If the shipping container is not damaged, unpack the unit. Save ship-
ping materials for repackaging.
3. Inspect unit for visual signs of damage.
Note: If there is damage, immediately notify the shipping carrier
and Bird Electronic Corporation.
Setup
Setup consists of three basic steps: moving the unit into position, adding cool-
ant, and connecting AC power and the RF line. These steps are explained in
more detail below.
z Use the HPCC in a dry, dust-free and vibration-free environment.
Note: Do not use outdoors or in areas of condensing humidity.
z Allow a minimum of one foot clearance along the sides and three feet
over the top to allow unobstructed air intake and exhaust.
z Surrounding air must be free of contaminants or particles that could
be drawn into the air intakes.
z The AC power supply required is 115/230 V @ 50/60 Hz, 1φ.
Note: The unit is equipped with an unterminated, reractable
power cord. Connect a power plug to this cord, appropriate to local
power source.
WARNING
Do not attempt to lift the cart by the handle.
CAUTION
Check the electrical code for proper AC hookup prior to operation of the
unit. Make sure the neutral or return hookup is only used for that purpose.
CAUTION
Do not block air flow. The air intake vents on the side of the heat exchanger
and the exhaust on top must not be obstructed.
