ix
About This Manual
Numbering
This manual covers the operating and maintenance instructions for the following
models:
Cal Cart with 4421 meter, 4028B10M sensor,
8640 load, 1-5/8” flanged connector,
115Vac power supply and standard US plug
Changes to this Manual
We have made every effort to ensure this manual is accurate. If you discover any
errors, or if you have suggestions for improving this manual, please send your
comments to our Solon, Ohio factory. This manual may be periodically updated.
When inquiring about updates to this manual refer to the part number and revi-
sion on the title page.
Terminology
There are some unique terms used throughout this literature. They are defined
here clarify any misunderstanding.
Cal Cart -
The entire unit.
Sensor - The power sensor
Meter- The power meter and display
Load - The entire load (water-cooled RF termination).
Resistor Assembly - The load component which connects directly to the RF line.
It is inside the HEAT EXCHANGER, connected by two hoses.
Heat Exchanger -
The parts of the Moduload left when the LOAD is removed. It
contains the pump, fans, coolant reservoir, and controls.
Resistor -
A subcomponent of the RESISTOR ASSEMBLY. This is the ceramic
resistor which actually absorbs the RF power.
SCC81 01 01 01 1
Sensor Load RF Connector
Voltage and
Plug Style
01 4028B10M 01 8640 Series 01 1-5/8” EIA
Flanged
1 115V, 15A
Nema 5-15P
02 8640B Series 2 230V, 30A
Nema L6-30P
3 115V, 10A
International
4 230V, 10A
International
