Bendix Commercial Vehicle Systems BRAKE APPLICATION GUIDELINES - Manual (Page 18)

17
For all vocations additional lining options available. Submit application request for possible approval.
All brakes shown with max GAWR less than 29,000 lb meet FMVSS-121, S5.4 dynamometer requirements. For all
brakes shown with max GAWR of 29,000 lb and greater, FMVSS-121 is not applicable.
Recommended Options
• Wide brake package for longer brake life to reduce operating cost, see page 34
• LMS (Low-Maintenance System) brakes and hubs for extended lubrication intervals, simplifi ed hub installation and reduced
bearing endplay
• ADB (air disc brake) on steer axles for improved braking performance
• ADB (air disc brake) on all vehicle axles for improved fade resistance and stopping power
• Bendix
® automatic slack adjusters (ASA) for maximized S-cam brake performance
Notes: 1. LS - Indicates Long stroke chamber
2. * - Indicates Combination lining block
3. Minimum drum weight of 54 kg (120 lb) is required
4. Mixing of ADB (Air disc brakes) on steer axle and S-cam brakes (drive axle) require BSFB application approval.
Brake Max. Max. Air Chamber Brake Adjuster
Model GAWR (lb) SLR (in) Linings Size (in 2 ) Length (in) Notes
Steer Axle Brakes
ES1655D 13,200 21.5 ES420,440,450S,600 20 or 24 5.5
ES1655D 16,000 21.5 ES420,440,600 24 5.5
ES1656D 16,000 21.5 ES420,440,600 24 5.5
ES1656D 22,000 21.5 ES1100/600*,1050 24 5.5 2
ES1656D 24,000 21.5 ES1100 24 5.5
ES1657D 20,000 21.5 ES420 30 5.5
ES1657D 22,000 21.5 ES600 30 5.5
ES1657D 24,000 21.5 ES690 30 5.5
ADB22X 20,000 21.5 Bendix ® 20 N/A
Drive Axle Brakes
ES1657D 20,000 21.5 ES410,420,440,600 30 5.5
ES1657D 22,000 21.5 ES600 30 5.5
ES1657D 23,000 22.0 ES690 30 5.5
ES1657S 26,000 22.0 ES900,1050 30 6.0 3
ES1657M 26,000 22.0 ES1100/800* 30 6.0 2,3
ES1657H 32,500 22.7 ES1100 30 6.0 3
ES1658D 23,000 20.7 ES420 30 5.5
ES1658D 23,000 22.0 ES420 30 6.0
ES1658S 29,000 20.5 ES900,1050 30 LS 6.0 1,3
EB1807R 32,500 22.7 E190HS,E290HS 30 LS 6.0 1,3
ADB22X 23,000 21.5 Bendix ® 18 N/A
Logging
