Bendix
®
BA-921
®
Compressor Installation and Application Review
Section IV
Air System Components (cont’d)
Compressor Air Induction System - Naturally Aspirated Compressor Applications Only
(Cont’d)
Line
size
_____________________________________
Line
length
___________________________________
Expected/Measured
Worst-Case Inlet Air Temperature: _______________
Was measured restriction less than 25 in H
2
O? YES
NO
Is the inlet air temperature greater than 170°F? YES
NO
Recommended Test Procedure:
Install a temperature probe in the air compressor inlet hose or fitting as close to the
compressor as possible. Operate the vehicle such that the engine is at operating
temperature and the compressor is loaded/pumping. Record the compressor air inlet
temperature and note the ambient temperature. To obtain the maximum air inlet
temperature, add the difference between the recorded inlet temperature and the noted
ambient temperature to the maximum expected ambient temperature.
Was the restriction measured per the recommended procedure? YES
NO
If no, describe the procedure used: ___________________________________________
_______________________________________________________________________
_______________________________________________________________________
_______________________________________________________________________
