USER MANUAL
7
LEDONARDO 1
WWW.BROTHERS-SONS.DK
1. Remove the two screws holding the cable strain relief and
pull the cable thorugh the side of the lamp housing.
2. Remove the two srews holding the on/off switch box.
3. Remove the screw holding the two earth/ground wires on
the side of the lamp housing.
4
5
Remove the four screws on the side near the bottom of the
lamp housing.
Mount the bottom frame with four Philips PH2 screws and 4
serrated washers as shown.
Note: the notch in the bottom frame is on the same side as the
focus handles.
6
user manual rev. 1.06
