Brother, Brother & Sons Ledonardo1 Ver. 2 - Manual (Page 10)

USER MANUAL
9
LEDONARDO 1
WWW.BROTHERS-SONS.DK
Raise the LED assembly approx. 5 mm / 0,2” by inserting e.g. a
screwdriver in both ends.
Lower the Main housing on to the Ledonardo as shown and
turn it 90º counter clockwise.
Remove whatever you used to raise the LED assembly.
10
12
11
Mount Ledonardo on the main housing, using eight Philips PH2
screws and eight serrated washers, as shown.
Assuming you did as instructed the conversion is done.
Think of all the birds sitting in the tree top, with a clear blue sky
as the backdrop, singing your praise for saving the environ-
ment, so their kids can grow up in a safer world.
....listen.... you can almost hear them singing: “what a
wonderful world”.
When lowering the Main housing on to the Ledonardo, make
sure to fit the cabels rubber grommet, into the notch on the
side of the Main housing.
5 mm / 0,2”
user manual rev. 1.06
