USER MANUAL
6
LEDONARDO 1
WWW.BROTHERS-SONS.DK
Unscrew the four screws as illustrated.
Note: You need to turn the lamp housing 90º when taking it out.
1
2
Using a screwdriver, remove the four locking rings on the guide
bar.
Slide the guide bar out and lift up the lampsocket / reflector
part. Be carefull not to loose the locking rings as you will need
them later.
NOTE:
The guide bar is not symmetrical, so it is recommended to mark
one end, to make sure that you remount it correctly.
Not doing so will affect the optical system.
Remove the screw on the side of the socket to detach the
earth/ground wire.
Loosen the to screws in the bottom of the socket to detach the
power cable.
3
user manual rev. 1.06
