Baumfolder Older Folder User Manual
Instruction manual older folder models, Baumfolder corporation

Baumfolder Corporation
Instruction Manual
Older Folder Models
These instructions are written as a generic instruction manual for all older folders. If you
have a Mark 2 or any other folder that has fixed right angle(s), where all sections are
fastened together, ignore information where it mentions height of unit or movement of any
section. The main difference of the fixed frame units is that you must remove the cross
carrier to add the stacker after each unit.
Before working on the folder, DISCONNECT ALL ELECTRICAL POWER SUPPLY TO THE
FOLDER to prevent the accidental start of the folder. Check to be sure you have the
correct tools to complete the job.
For reasons of safety, long hair must be tied back or otherwise secured, garments must be
close fitting and no jewelry, such as rings or necklaces, may be worn while adjusting or
setting up equipment. Injury may result from being caught up in the machinery or jewelry
catching in moving parts.
Good luck and good folding. You have a piece of equipment that was
built with pride, quality parts and quality people.
Baumfolder Corporation
1660 Campbell Rd. Sidney, OH 45365 Copyright © 2002
Ph: 1-800-543-6107 Fax: 937-492-7280 email: [email protected]
1
Document Outline
- CONTENTS
- THEORY OF OPERATION 3
- REGISTER TABLE ADJUSTMENT 4
- REGISTER TAPES AND TUCK IN SHOES 5
- PROCEDURE FOR SETTING UP A
- MECHANICAL PILE FEEDER 6
- OPERATING A FRICTION FEED BAUMFOLDER11
- STACKER AND STACKER PAN17
- FIRST RIGHT ANGLE / EIGHT-PAGE SECTION18
