PAGE 27 TP10456-EN
OUTPUT REMARKS
3 STOP SOLENOID
TEST
1 FEED WHEEL TEST
The Feed Wheel should turn on when entering this test and turn off
when the arrow keys are used to select another test. If the Feed Wheel
is not rotating, verify the motor wiring and check dc motor control
The Sheet Stop Solenoid should energize when entering this test and
turn off when the arrow keys are used to select another test. If the
Sheet Stop Solenoid does not energize, check solenoid wiring and
voltage (12 Vdc). This solenoid is not installed on all Feeders.
2 FEED SOLENOID
TEST
The Feed Solenoid should energize when entering this test and turn off
when the arrow keys are used to select another test. If the Feed
Solenoid does not energize, check solenoid wiring and voltage (12
Vdc).
18.0.4 PILE FEEDER INDICATOR TESTS
These tests will test the operation of the each indicator on the operator panel. Exiting this Diagnostic
program can be done at any time by scrolling to the EXIT screen and pressing the Enter Key, 7.
1. Turn the main Pile Feeder Power Switch on.
2. Press the Pile Feeder Start Key, 2.
3. Press the Diagnostic Key, 5. The message
will be displayed.
DIAGNOSTIC
(Y) ENTER (N) RESET
4. Press the Enter Key, 7, to enter the diagnostic tests or press the Reset Key, 5, to exit. The message
will be displayed, if Enter Key is pressed.
KEYPAD TESTS
PRESS ENTER
5. Press the Up Arrow Key, 14, until the message
is displayed.
6. Press the Enter Key, 7, to enter the Indicator Test, and the message
will be displayed.
INDICATOR TESTS
PRESS ENTER
BATCH COUNT
INDICATOR OFF
