9. Press the Enter Key, 7, and the operator panel will return to the
screen.
10. Use the Up Arrow Key, 14, until the message
is displayed.
11. Press Enter Key, 7, and the operator panel display will return to the main count screen.
SENSOR TESTS
PRESS ENTER
PRESS ENTER
TO EXIT TESTS
18.0.3 PILE FEEDER OUTPUT TESTS
This group of tests will help to verify the operation of the output circuits contained in the Output Circuit
Test table. Exiting this Diagnostic program can be done at any time by scrolling to the EXIT screen and pressing
the Enter Key, 7.
1. Turn the main Pile Feeder Power Switch on.
2. Press the Pile Feeder Start Key, 2.
3. Press the Diagnostic Key, 5. The message
will be displayed.
DIAGNOSTIC
(Y) ENTER (N) RESET
SHEET COUNT SENSOR INACTIVE ACTIVE Place sheet under sensor
PILE HEIGHT SENSOR INACTIVE ACTIVE Place hand under sensor
DOUBLE SHEET SENSOR INACTIVE ACTIVE Manually trip Double Sheet Detector
DOWN LIMIT SWITCH INACTIVE ACTIVE Manually trip switch
UP SAFETY SWITCH INACTIVE ACTIVE Manually trip switch
DOWN SAFETY SWITCH INACTIVE ACTIVE Manually trip switch
PILE LOAD SENSOR INACTIVE ACTIVE
Ensure table or product is breaking
sensor beam. Place hand in
photobeam path.
INHIBIT INPUT
(1st Station required)
ACTIVE INACTIVE
Start 1st station or disconnect
communication cable from 1st station
NORMAL
STATE
SENSOR ACTIVATION
SENSOR
DESIGNATION
OPERATED
STATE
Slowly rotate 1st station handwheel HIGH LOW
ENCODER INPUT
(1st Station required)
