PAGE 23 TP10456-EN
1. Turn the main Pile Feeder Power Switch on.
2. Press the Pile Feeder Start Key, 2.
3. Press the Diagnostic Key, 5. The message
will be displayed.
4. Press the Enter Key, 7, to enter the diagnostic tests or press the Reset Key, 5, to exit. The message
will be displayed, if Enter Key is pressed.
DIAGNOSTIC
(Y) ENTER (N) RESET
KEYPAD TESTS
PRESS ENTER
5. Press the Enter Key, 7, to enter the keyboard tests. The message
will be displayed if Enter Key is pressed.
6. Press the Table Up Key, 10, and the display should switch between to “ACTIVE” each time the
Table Up Key is pressed. If the display shows that the Table Up Key is still inactive while the switch is pressed,
then there is a problem with the display assembly, communication cable or controller board.
PRESS TABLE UP KEY
INACTIVE
8. Select each Keypad Key by using the Up/Down Arrow Keys, 14/13, and test each corresponding
Keypad Key. As each key is operated, the status should switch between “INACTIVE” and “ACTIVE”. The
table below shows what each Keypad Key’s normal and operated state should be.
TABLE UP INACTIVE ACTIVE
TABLE STOP INACTIVE ACTIVE
TABLE DOWN INACTIVE ACTIVE
TOTAL COUNTER INACTIVE ACTIVE
SET BATCH COUNTER INACTIVE ACTIVE
ENTER INACTIVE ACTIVE
RESET INACTIVE ACTIVE
SHEET START INACTIVE ACTIVE
SHEET MODE INACTIVE ACTIVE
SHEET GAP INACTIVE ACTIVE
PILE FEEDER VERSION 1.00 SOFTWARE INSTALLED
NORMAL
STATE
OPERATED
STATE
KEYPAD KEY
DESIGNATION
PUMP (Standalone
Versions Only)
INACTIVE ACTIVE
