Baumfolder BAUM20: 20 Kicker Assembly Installation User Manual
Page 8

TP10324A
PAGE 8
+
Batching Time Adjustment
The batching time adjustments allow the user to select the
time duration associated with the currently selected output
type. Two output types and times are available.
1. Feed interrupt has a range of 0.0 to 9.9 seconds.
2. Speed-up Table has a range of 0.00 to 5.00 seconds.
Set the range at approximately 0.5.
2.3 Make Ready Mode
This key places the controller in the make ready mode.
The key LED goes on. In this mode the folder will only feed
single sheets and a batching output is issued for every two
sheets fed. This allows the operator to easily set up the
batching time.
Press the make ready button.
Press the sheet feed button, one sheet will be fed. The
system will measure the sheet and automatically set some
tiking parameters.
After each second sheet the Kicker will activate. Adjust
the Kicker timing by changing thebatching time in the counter
setup mode. This will achieve the desired offset (index) for
the batch point.
Press the Make Ready button (#23). Its LED should go
out informing you that the system is ready for production.
